Inside Aprilia

Photos and Words by Sam Quarelli Fleming


In 1999 Aprilia split its core operations into two locations in Northern Italy. A new assembly plant was opened in Scorze while the design, race, corporate and testing facilities took over the original headquarters a few miles away in Noale. Part I of this pictorial depicts the Scorze assembly plant, part II explores the Noale facility. Neither of these locations have tours for visitors yet so, for the meantime, these pictures will have to suffice.



Part I

Aprilia Production Facility

Scorze, Venezia, Italy



Aprilia is a cutting edge motor company in that it specializes in design, branding,
quality and assembly but it subcontracts virtually all of the component manufacturing.
You will see many more car companies heading this direction in the future. The assembly
plant puts together over one thousand scooter and motorcycles a day. Constructed
in 1999, the plant has beautiful modern architecture inside and out.





Here scooter frames arrive from Benelli and are stacked in the parking lot.
Most of these will be scooters by the end of the day.





Cast frames for 125cc road bikes. Unfortunately these are not the same type
of cast frames as are coming out of Japan right now but it is only a matter of time.





Scooter engines ready for installation. Aprilia buys engines
from multiple sources within Italy as well as Austria and Japan.
The plant produces over 800 scooters and over 200 motorcycles
a day.





V60 engines factory fresh from Rotax in Austria destined for RSVs everywhere.





RSV Factory frames from Benelli are patiently waiting their
turn on the line.





Where the magic happens. Most of the workers are the Aprilia
plant are contract labor to allow for easier increases or decreases
of staffing levels to match demand for machines.





Aprilia is still a young and relatively small motor company. Like Ducati ten years ago,
there are no regular tours of the factory. In our case the person with the best English
skills was Paola who is one of the assembly line troubleshooters on the RSV line. When
someone has a problem with an assembly operation they illuminate a light and Paola
fixes the problem for them. I tried to get her cell phone number so if any of you have
any problems with the assembly of your RSVs you would be able to call her directly
for the solution but for some reason she would only give the number in Italian.





RSV R (the shiny frames and plain Jane forks give it away) have completed their
initial assembly and are staged for the installation of subframes and bodywork.





The entire factory is very stylish and the walls are decorated
with pictures of celebrities on Aprilia products.





Italian style and sensibilities dictate that beauty be everywhere. For that reason the
portion of the assembly line dedicated for installation of bodywork is staffed by donne
belle giovani.





Aprilia is very stringent about quality control. Each bike is rolling road dyno tested
at the end of the assembly line.





Rejected parts are placed in a few bins. The Aprilia plant then has a room with about
ten people in it that liaison with the subcontractors and suppliers regarding quality
of products provided.





In a room near the end of the assembly line selected vehicles are completely torn
down to their component parts to determine if any mistakes or errors where made
during the assembly. This feedback loop allows the assembly line to quickly remedy
any structural process problems.





The assembly plant is in a separate building a short distance
away from the finished product warehouse. Complete vehicles
are loaded onto a conveyor system which raises them up about
forty feet, over a couple hundred and then back down to ground
level in the warehouse.





With 1,200 or so vehicles coming off the line each day this warehouse can fill up
quickly. Despite its “Raiders of the Lost Ark” appearance the bikes do not languish
here for long.



In keeping with Aprilia’s lean “just in time” delivery system most of these bikes will be
shipped out within a week and the whole warehouse is usually turned over within three weeks.



Part II



The Noale complex is spread out amongst a number of different buildings which
house the business offices, the race shops for the factory race teams, the corse
departments (for the sale of GP bikes), the design shops and the research and
development testing centers. Noale also has the original assembly line building
which is being converted to an Aprilia museum. Several large signs are decorating
the campus from a worldwide Aprilia celebration they hosted in Noale. Valentino
Rossi, the most popular racer in Italy, is still featured prominently around Aprilia.



Corse



Aprilia Corse is a separate division within Aprilia. Corse is responsible for the sale of
race bikes, sponsorship relations and the management of the factory race teams.
Since Aprilia is privately held by Ivano Beggio, basically you have one man writing
a check for an entire MotoGP, 250GP and 125GP racing effort. No wonder they eased
out of WSBK. Corse has its own offices in this distinct building (there is an interview
with Jan Witteveen, the Director of Aprilia Corse, elsewhere in this issue).





Corse is responsible for the supply of spare parts for all Aprilia race bikes in the
world. They try to keep parts availability for models produced within the last five years.





The cube is not down to the minimum weight allowed for triples. Carbon
wheels and a beautiful carbon swing arm (not shown) indicate how Aprilia
plans to get there.





French Italian Didier Lambert works for Corse. Historically
attached to the WSBK program he now works with GP. He
is holding an Aprilia instrument cluster which incorporates
the instruments, the FI management and a data acquisition
unit. “It is great unless the rider crashes a lot”.





This is the factory reference for the building of 125cc GP race bikes. Although
a hard number was difficult to pry out of anyone it seemed that Corse produces
about 60 125 racers and about 15 250cc racebikes a year which range in
specification and, accordingly, price. 250cc racebikes start at $85,000 with
a realistic annual budget of about $200,000. Unfortunately this will only get
you into the top thirty or so in World GP. Top ten is about $500,000 and top
three is $1,000,000. And that is just for the bikes and spares.





Technicians building something fast for Colin.





A Corse technician is putting an Ohlins race shock through some tests on
a shock dyno. The room is equipped to assemble and test both front and
rear suspension units.





Run of the mill Ohlins carbon fiber sleeved forks bolted
into testing triple trees for suspension dyno work.





The GP race transporters are lined up across from the GP garages.





Peering into the GP garages (photos were not allowed of the cube and the
cube motor) the transportation crates and victory bottles of champagne
are visible. The GP garages get their very own building which is separate
and distinct from the Corse business, parts and assembly building.



Research and Development



The Halls of Science! Sound proofed rooms off to either
side of this corridor are used to test engines, chassis
components and even entire bikes. This facility is shared
by Aprilia Corse, the scooter teams and the streetbike teams.





Beggio has purchased Moto Guzzi and Laverda. Moto Guzzi is being revived
slowly although its engine blocks still feature the casting to mount the ignition
distributor used in the early 1970s. Moto Guzzi products are benefiting from
access to the sophisticated Aprilia testing facilities.





Mike Ambler (Australian) worked for Orbital. Orbital pioneered some of the
gasoline based direct injection systems. Direct injection systems introduce
fuel straight into the combustion chamber. Various forms of direct injection
are used in diesel engines in the US. Aprilia is using direct injection on some
of its small scooter engines because direct injection allows for running
extremely lean mixtures. Whereas many gasoline motors run best around
14:1 AFR (Air Fuel Ratio) direct injection motors can run at 75 or even 100:1.
This allows for low emission scooters which can achieve over 150 miles per
gallon. Zoinks. Here Mike watches a Moto Guzzi shock be compressed over
and over and over again.





Aprilia is very serious about testing and quality. This rig allows for a virtual
rider to activate the brakes, the clutch, shift gears, open the throttle and
weight the seat 24 hours a day for 365 days a year with no chance of accident.
The bike can be rigged with a variety of testing equipment to capture data
on wear and tear, temperatures, vibration, noise or any other indicators.
This allows Aprilia to put many miles on its vehicles in a very short period
of time in order to rapidly respond to change in the market while keeping
the quality of the final products very high.





The chassis squeezer. This machine compresses a chassis lengthwise, ie,
not up and down but front to back. The stroke on the machine was about
25mm or so. The scooter chassis, therefore, has to be able to withstand
that amount of flex for a long long time. Built for Roman paved cobble
stone streets of Italy, these scooters should last forever in the US. An
interesting note, any Aprilia aftermarket equipment (tail trunk, mufflers,
etc) has withstood the full range of Aprilia testing for suitability and durability.





Despite the sophisticated testing facility just to the right of this group of
young men, sometimes you just need to fire up a 125cc race bike in the
parking lot and make some NOISE! These Aprilia technicians demonstrate.
